Copper Plate Stamping Distributor
Description
Designed in all copper structure, this distributor is a thin-walled distributor through cold stamping and rolling molding. Its key features include:
(1) The lowest cost among all distributors;
(2) All copper structure, which achieves outstanding effect in welding;
(3) Large cavity design, which achieves obvious mute effect;
(4) New design with filter screen, which solves the potential defect of uneven gas-liquid mixing
Type A
Type B
Number of distributor holes:
2-10 holes
Copper plate stamping distributor size
| Type | Connected capillary specification (inch) | Number of distributor holes | A | B
(mm) |
C
(mm) |
D (0,
+0.015) (inch) |
|---|---|---|---|---|---|---|
| A | 5/32,3/16,1/4, 5/16,3/8 | 2-10 | 25-70 | 6-15 | 6-15.88 | 5/32,3/16,1/4, 5/16,3/8 |
How to choose a copper plate stamping distributor?
Step 1: Provide information to us according to the following table;
| Type | Connected capillary specification | Number of distributor holes | A | B | C | D |
|---|---|---|---|---|---|---|
| ? A. Recommended according to your requirements | ? | ? | Recommended unless otherwise specified | |||
Step 2: We provide drawings for your confirmation;
Step 3: Confirm the drawings and arrange samples.
