ACR Pancake Coil (ASTM B280)

Gold Stone HVACR Inc. offers premium ACR Coils for Wholesalers & Suppliers at competitive prices and expedited delivery times.  With a minimum of 99.9% pure copper tube (Alloy 12200), our pancake coil / copper tubing is among the highest quality ACR coils available for your cooling or refrigeration systems.

Description

Key Features of ACR & Gas Coils / Wholesaler & Supplier

With better parts, we create superior cooling systems which reduces breakdowns and improves performance. Gold Stone HVACR Inc.’s ACR Coils / Wholesaler & Supplier make this possible by meeting or exceeding quality standards to ensure optimal performance with the following features:

  • ACR Coil is a minimum of 99.9% pure copper tube (Alloy 12200)
  • Tube supplied meets or exceeds ASTM B280 (with “ACR” incised on tubes)
  • Capped plain ends



Standard:            ASTM B280



Copper Alloy:     C12200

Temper:               060 or H58

Finish:                   Dehydrated, cleaned and capped



Size:                       ¼” to 1-1/8”

Length:                 50’ pancake coil (25’ and 100’ pancake coils can be requested)

Marking:              Incised



Product Name Product No. Part No. Description O.D. W. Length Case Size QTY / Case
(in.) (kg) (ft) mm*mm*mm unit
ACR COILS ACR 1/4 R 50 ACR 1/4 R 50 ACR Pancake Coil 1/4” 1/4 50 15
ACR 3/8 R 50 ACR 3/8 R 50 ACR Pancake Coil 3/8” 3/8 50 8
ACR 1/2 R 50 ACR 1/2 R 50 ACR Pancake Coil 1/2” 1/2 50 8
ACR 5/8 R 50 ACR 5/8 R 50 ACR Pancake Coil 5/8” 5/8 50 6
ACR 3/4 R 50 ACR 3/4 R 50 ACR Pancake Coil 3/4” 3/4 50 5
ACR 7/8 R 50 ACR 7/8 R 50 ACR Pancake Coil 7/8” 7/8 50 4
ACR 1-1/8″ R 50 ACR 1-1/8″ R 50 ACR Pancake Coil 1 1/8” 1 1/8 50 3
